Model
P6039A
Division Ratio
1000：1
Read Out
－
Input Resistance
900MΩ
Input Capacitor
2.0PF
Max. DC+AC pack
40KV CAT ‖
Max. AC RMS.
28KV CAT ‖
Max. Loading Current
45uA
Band Width
DC~220MHz
Rise Time
1.6 ns
Signal /Noise
>60dB at 1KHz; >50dB at 1MHz
DCV Accuracy
≦3% Full Range
ACV Accuracy
≦3% at 1KHz
Temp. Coefficient
≦200 PPM/℃
Compensation Range
10PF~35PF
Safety
Meets EN61010-031CAT‖
Cable Length
2M±0.2M
Operation Temp.
-10~55℃
Humidity
85%RH or less(at 35℃)
Storage Temp.
-20~70℃
Color: Handel/Body
Black/ Red
Weight /Volume
460g/80(W)×80(H) ×320(L)mm
